Asus M4N68T-M LE NVIDIA RAID

Asus M4N68T-M LE NVIDIA RAID Driver descriptionCPU
AMD Socket AM3 ;PhenomII /AthlonII /Sempron 100 Series Processors
AMD Cool Quiet Technology
AMD 64 architecture enables simultaneous 32-bit and 64-bit computing

Chipset
NVIDIA Geforce 7025/nForce 630a

System Bus
Up to 2000/1600 MT/s

Memory
2 x DIMM, Max. 8 GB, DDR3 1800(O.C.)/1600(O.C.)/1333/1066 ECC,Non-ECC,Un-buffered Memory
Dual Channel memory architecture

Expansion Slots
1 x PCIe x16
1 x PCIe x1
2 x PCI

VGA
Integrated Programmable Shader model3.0 DirectX 9 graphics processor
Max. shared memory: 256 MB
Supports RGB with max. resolution 1920 x1440 (@75Hz)

Storage Southbridge
1 xUltraDMA 133/100
4 xSATA 3 Gb/s ports Support RAID 0,1,5,10,JBOD

LAN
Gb LAN

Audio
VT1708S High Definition Audio 8-Channel CODEC
*Choose the chassis with HD audio module in front panel to support 8-Channel audio output
- Support S/PDIF out interface
- Support Multi-streaming, Single SPDIF Out, Anti-pop Function

USB
10 USB 2.0/1.1 ports (6 ports at mid-board, 4 ports at back panel)

ASUS Unique Features
ASUS EPU-4 Engine
ASUS Express Gate
ASUS Q-Fan
ASUS CrashFree BIOS 3
ASUS EZ Flash 2
ASUS AI NET 2
ASUS MyLogo 2

Overclocking Features
Intelligent overclocking tools
- ASUS Turbo Key
SFS (Stepless Frequency Selection)
- PCI Express frequency tuning from 100MHz up to 150MHz at 1MHz increment
- HT tuning from 200MHz up to 550MHz at 1MHz increment
Overclocking Protection
- ASUS C.P.R.(CPU Parameter Recall)

Back Panel I/O Ports
1 x Parallel port
1 x VGA
1 x PS/2 Keyboard
1 x PS/2 Mouse
1 x LAN(RJ45) port
4 x USB 2.0/1.1
1 x COM port
3 x Audio jacks

Internal I/O Connectors
3 x USB connectors (6 ports)
1 x IDE connector
4 x SATA connectors
1 x CPU Fan connector
1 x Chassis Fan connector
1 x Front panel audio connector
1 x SPDIF out
1 x Internal speaker connector
1 x 24-pin EATX Power connector
1 x 4-pin ATX 12V Power connector
1 x System Panel connector

BIOS
8 Mb Flash ROM , AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS v2.5, ACPI 2.0a

Accessories
Users manual
1 x I/O Shield
2 x SATA cable(s)
1 x UltraDMA 133/100 cable

Support Disc
Drivers
ASUS PC Probe II
Anti-virus software (OEM version)
ASUS Update

Form Factor
uATX Form Factor
9.6 inch x 8.2 inch ( 24.4 cm x 20.8 cm )
