Gigabyte GA-880GM-USB3 NEC USB 3.0 Driver 1.0.18.0 descriptionCPU
1. Support for AM3 processors: AMD Phenom II processor/ AMD Athlon II processor

Hyper Transport Bus
1. 5200 MT/s

Chipset
1. North Bridge: AMD 880G
2. South Bridge: AMD SB710

Memory
1. 4 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory
2. Dual channel memory architecture
3. Support for DDR3 1800 (OC)/1666/1333/1066 MHz memory modules

Onboard Graphics
Integrated in the North Bridge:
1. 1 x D-Sub port
2. 1 x DVI-D port
3. 1 x HDMI port

Audio
1. Realtek ALC892 codec
2. High Definition Audio
3. 2/4/5.1/7.1-channel
4. Support for Dolby Home Theater
5. Support for S/PDIF In/Out
6. Support for CD In

LAN
1. Realtek 8111D chip (10/100/1000 Mbit)

Expansion Slots
1. 1 x PCI Express x16 slot, running at x16 (PCIEX16)
(The PCI Express x16 slot conforms to PCI Express 2.0 standard.)
2. 1 x PCI Express x1 slot
3. 2 x PCI slots

Storage Interface
South Bridge:
1. 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
2. 5 x SATA 3Gb/s connectors supporting up to 5 SATA 3Gb/s devices
3. 1 x eSATA 3Gb/s port on the back panel supporting up to 1 SATA 3Gb/s device
4. Support for SATA RAID 0, RAID 1, RAID 10 and JBOD

iTE IT8720 chip:
1. 1 x floppy disk drive connector supporting up to 1 floppy disk drive

USB
South Bridge:
1. Up to 12 USB 2.0/1.1 ports (Note 5) (6 on the back panel, 6 via the USB brackets connected to the internal USB headers)

NEC D720200F1 chip:
1. Up to 2 USB3.0 ports on the back panel

IEEE 1394
T.I. TSB43AB23 chip:
1. Up to 2 IEEE 1394a ports (1 on the back panel, 1 via the IEEE 1394a bracket connected to the internal IEEE 1394a header)

Internal I/O Connectors
1. 1 x 24-pin ATX main power connector
2. 1 x 8-pin ATX 12V power connector
3. 1 x floppy disk drive connector
4. 1 x IDE connector
5. 5 x SATA 3Gb/s connectors
6. 1 x CPU fan header
7. 1 x system fan header
8. 1 x front panel header
9. 1 x front panel audio header
10. 1 x CD In connector
11. 1 x S/PDIF In/Out header
12. 3 x USB 2.0/1.1 headers
13. 1 x IEEE 1394a header
14. 1 x serial port header
15. 1 x clearing CMOS jumper

Back Panel Connectors
1. 1 x PS/2 keyboard port or PS/2 mouse port
2. 1 x D-Sub port
3. 1 x DVI-D port
4. 1 x HDMI port
5. 1 x optical S/PDIF Out connector
6. 1 x eSATA 3Gb/s port
7. 1 x IEEE 1394a port
8. 4 x USB 2.0/1.1 ports
9. 2 x USB 3.0/2.0 ports
10. 1 x RJ-45 port
11. 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line Out/Microphone)

I/O Controller
1. ITE IT8720 chip

H/W Monitoring
1. System voltage detection
2. CPU/System temperature detection
3. CPU/System fan speed detection
4. CPU overheating warning
5. CPU/System/Power fan fail warning
6. CPU/System fan speed control

BIOS
1. 2 x 8 Mbit flash
2. Use of licensed AWARD BIOS
3. Support for DualBIOS
4. PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b

Unique Features
1. Support for @BIOS
2. Support for Q-Flash
3. Support for Xpress BIOS Rescue
4. Support for Download Center
5. Support for Xpress Install
6. Support for Xpress Recovery2
7. Support for EasyTune
8. Support for Easy Energy Saver
9. Support for Time Repare
10. Support for Q-Share
11. Support for Auto Green

Bundle Software
1. Norton Internet Security (OEM version)

Form Factor
1. Micro ATX Form Factor; 24.4cm x 24.4cm
