Gigabyte GA-EG41M-S2H Bios
version F4B Beta | windows
Name: Gigabyte GA-EG41M-S2H Bios
Version: F4B Beta
Size: 552.39 KB
Category: Miscellaneous
License: Free
Released: 2013-12-11
Developer: Gigabyte Technology, Inc.
Downloads: 844
Version: F4B Beta
Size: 552.39 KB
Category: Miscellaneous
License: Free
Released: 2013-12-11
Developer: Gigabyte Technology, Inc.
Downloads: 844
Rate this software: |
Description
Gigabyte GA-EG41M-S2H Bios F4B Beta descriptionCPU1. Support for an Intel Core 2 Extreme processor/ Intel Core 2 Quad processor/Intel Core 2 Duo processor/Intel Pentium Dual-Core processo/Intel Celeron processor in the LGA 775 package
2. L2 cache varies with CPU
Front Side Bus
1. 1333/1066/800 MHz FSB
Chipset
1. North Bridge: Intel G41 Chipset
2. South Bridge: Intel ICH7
Memory
1. 2 x 1.8V DDR2 DIMM sockets supporting up to 8 GB of system memory
2. Dual channel memory architecture
3. Support for DDR2 1066(OC)/800/667 MHz memory modules
Onboard Graphics
North Bridge:
1. 1 x D-Sub port
2. 1 x DVI-D port
SiI1392 chip:
1. 1 x HDMI port
Audio
1. Realtek ALC888 codec
2. High Definition Audio
3. 2/4/5.1/7.1-channel
4. Support for S/PDIF In/Out
5. Support for CD In
LAN
1. Realtek 8110SC chip (10/100/1000 Mbit)
Expansion Slots
1. 1 x PCI Express x16 slot, running at x4 (Refer to the graphics cards support list.)
2. 3 x PCI slots
Storage Interface
South Bridge:
1. 1 x IDE connector supporting ATA-100/66/33 and up to 2 IDE devices
2. 4 x SATA 3Gb/s connectors supporting up to 4 SATA 3Gb/s devices
iTE IT8718 chip:
1. 1 x floppy disk drive connector supporting up to 1 floppy disk drive
USB
1. Integrated in the South Bridge
2. Up to 8 USB 2.0/1.1 ports (4 on the back panel, 4 via the USB brackets connected to the internal USB headers)
Internal I/O Connectors
1. 1 x 24-pin ATX main power connector
2. 1 x 4-pin ATX 12V power connector
3. 1 x floppy disk drive connector
4. 1 x IDE connector
5. 4 x SATA 3Gb/s connectors
6. 1 x CPU fan header
7. 1 x system fan header
8. 1 x front panel header
9. 1 x front panel audio header
10. 1 x CD In connector
11. 1 x S/PDIF In header
12. 1 x S/PDIF Out header
13. 2 x USB 2.0/1.1 headers
14. 1 x serial port header
15. 1 x power LED header
16. 1 x chassis intrusion header
Back Panel Connectors
1. 1 x PS/2 keyboard port
2. 1 x PS/2 mouse port
3. 1 x D-Sub port
4. 1 x DVI-D port
5. 1 x HDMI port
6. 1 x optical S/PDIF Out connector
7. 4 x USB 2.0/1.1 ports
8. 1 x RJ-45 port
9. 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line out/Microphone)
I/O Controller
1. iTE IT8718 chip
H/W Monitoring
1. System voltage detection
2. CPU/System temperature detection
3. CPU/System fan speed detection
4. CPU overheating warning
5. CPU/System fan fail warning
6. CPU/System fan speed control
BIOS
1. 2 x 8 Mbit flash
2. Use of licensed AWARD BIOS
3. Support for DualBIOS
4. PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features
1. Support for @BIOS
2. Support for Q-Flash
3. Support for Virtual Dual BIOS
4. Support for Download Center
5. Support for Xpress Install
6. Support for Xpress Recovery2
7. Support for EasyTune (Note 4)
8. Support for Dynamic Energy Saver Advanced
9. Support for Time Repair
10. Support for Q-Share
Bundle Software
1. Norton Internet Security (OEM version)
Form Factor
1. Micro ATX Form Factor; 24.4cm x 20.7cm
It is highly recommended to always use the most recent driver version available.
Do not forget to check with our site as often as possible in order to stay updated on the latest drivers, software and games.
Try to set a system restore point before installing a device driver. This will help if you installed a wrong driver. Problems can arise when your hardware device is too old or not supported any longer.
