Gigabyte GA-G41MT-D3 Bios

Gigabyte GA-G41MT-D3 Bios F1 descriptionCPU
1. Support for an Intel Core 2 Extreme processor/ Intel Core 2 Quad processor/Intel Core 2 Duo processor/ Intel Pentium processor/Intel Celeron processor in the LGA775 package
2. L2 cache varies with CPU

Front Side Bus
1. 1333/1066/800 MHz FSB

Chipset
1. North Bridge: Intel G41 Express Chipset
2. South Bridge: Intel ICH7

Memory
1. 2 x 1.5V DDR3 DIMM sockets supporting up to 4 GB of system memory
2. Dual channel memory architecture
3. Support for DDR3 1066/800 MHz memory modules

Onboard Graphics
Integrated in the North Bridge:
1. 1 x D-Sub port

Audio
1. Realtek ALC888B codec
2. High Definition Audio
3. 2/4/5.1/7.1-channel
4. Support for S/PDIF In/Out
5. Support for CD InLAN

LAN
1. 1 x Realtek RTL8111D/E chip (10/100/1000 Mbit)

Expansion Slots
1. 1 x PCI Express x16 slot, running at x16
2. 1 x PCI Express x1 slot
3. 2 x PCI slots

Storage Interface
South Bridge:
1. 1 x IDE connector supporting ATA-100/66/33 and up to 2 IDE devices
2. 4 x SATA 3Gb/s connectors supporting up to 4 SATA 3Gb/s devices

iTE IT8718 chip:
1. 1 x floppy disk drive connector supporting up to 1 floppy disk drive

USB
South Bridge
1. Up to 8 USB 2.0/1.1 ports (4 on the back panel, 4 via the USB brackets connected to the internal USB headers)

Internal I/O Connectors
1. 1 x 24-pin ATX main power connector Connectors
2. 1 x 4-pin ATX 12V power connector
3. 1 x floppy disk drive connector
4. 1 x IDE connector
5. 4 x SATA 3Gb/s connectors
6. 1 x CPU fan header
7. 1 x system fan header
8. 1 x front panel header
9. 1 x front panel audio header
10. 1 x CD In connector
11. 1 x S/PDIF In/Out header
12. 2 x USB 2.0/1.1 headers
13. 1 x serial port header
14. 1 x clearing CMOS jumper

Back Panel Connectors
1. 1 x PS/2 keyboard port Connectors
2. 1 x PS/2 mouse port
3. 1 x parallel port
4. 1 x serial port
5. 1 x D-Sub port
6. 4 x USB 2.0/1.1 ports
7. 1 x RJ-45 port
8. 3 x audio jacks (Line In/Line Out/Microphone)

I/O Controller
1. iTE IT8718

H/W Monitoring
1. System voltage detection
2. CPU/System temperature detection
3. CPU/System fan speed detection
4. CPU overheating warning
5. CPU/System fan fail warning
6. CPU fan speed control

BIOS
1. 2 x 8 Mbit flash
2. Use of licensed AWARD BIOS
3. Support for DualBIOS
4. PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b

Unique Features
1. Support for @BIOS
2. Support for Q-Flash
3. Support for Xpress BIOS Rescue
4. Support for Download Center
5. Support for Xpress Install
6. Support for Xpress Recovery2
7. Support for EasyTune
8. Support for Easy Energy Saver
9. Support for Time Repair
10. Support for Q-Share

Bundle Software
1. Norton Internet Security (OEM version)

Form Factor
1. Micro ATX Form Factor; 24.4cm x 19.4cm
