Gigabyte GA-MA790X-UD3P AMD Chipset Driver 8.641 for

Gigabyte GA-MA790X-UD3P AMD Chipset Driver 8.641 for Vista descriptionCPU
1. Support for AM3 / AM2+ / AM2 processors: AMD Phenom II X4 processor/ AMD Phenom II X3 processor/ AMD Phenom FX processor/ AMD Phenom X4 processor/ AMD Phenom X3 processor/ AMD Athlon X2 processor/ AMD Athlon processor/ AMD Sempron X2 processor/ AMD Sempronprocessor

Hyper Transport Bus
1. 5200/2000 MT/s

Chipset
1. North Bridge: AMD 790X
2. South Bridge: AMD SB750

Memory
1. 4 x 1.8V DDR2 DIMM sockets supporting up to 16 GB of system memory (Note 1)
2. Dual channel memory architecture
3. Support for DDR2 1333(O.C.)/1066(Note 2)/800 MHz memory modules

Audio
1. Realtek ALC888 codec
2. High Definition Audio
3. 2/4/5.1/7.1-channel
4. Support for S/PDIF In/Out
5. Support for CD In

LAN
1. Realtek 8111C chip (10/100/1000 Mbit)

Expansion Slots
1. 1 x PCI Express x16 slots, running at x16 (PCIEX16_1) (Note 3)
2. 1 x PCI Express x16 slots, running at x8 (PCIEX8_1) (Note 4)
(The PCIEX16_1 and PCIEX8_1 slots support ATI CrossFireX technology, and conform to PCI Express 2.0 standard.)
3. 3 x PCI Express x1 slots
4. 2 x PCI slots

Storage Interface South Bridge:
1. 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
2. 6 x SATA 3Gb/s connectors supporting up to 6 SATA 3Gb/s devices
3. Support for SATA RAID 0, RAID 1, RAID5, RAID 10 and JBOD

GIGABYTE SATA2 chip:
1. 2 x SATA 3Gb/s connectors (GSATA2_0, GSATA2_1) supporting up to 2 SATA 3Gb/s devices
2. Support for SATA RAID 0, RAID 1 and JBOD
iTE IT8720 chip:
1. 1 x floppy disk drive connector supporting up to 1 floppy disk drive

IEEE 1394 T.I. TSB43AB23 chip
1. Up to 3 IEEE 1394a ports (2 on the back panel, 1 via the IEEE 1394a bracket connected to the internal IEEE 1394a header)

USB Integrated in the South Bridge
1. Up to 12 USB 2.0/1.1 ports (8 on the back panel, 4 via the USB brackets connected to the internal USB headers)

Internal I/O Connectors
1. 1 x 24-pin ATX main power connector
2. 1 x 8-pin ATX 12V power connector
3. 1 x floppy disk drive connector
4. 1 x IDE connector
5. 8 x SATA 3Gb/s connectors
6. 1 x CPU fan header
7. 2 x system fan header
8. 1 x power fan header
9. 1 x front panel header
10. 1 x front panel audio header
11. 1 x CD In connector
12. 1 x S/PDIF In header
13. 1 x S/PDIF Out header
14. 1 x IEEE 1394a header
15. 2 x USB 2.0/1.1 headers
16. 1 x serial port header
17. 1 x chassis intrusion header
18. 1 x power LED header
19. 1 x clearing CMOS jumper

Back Panel Connectors
1. 1 x PS/2 keyboard port
2. 1 x PS/2 mouse port
3. 1 x optical S/PDIF Out connector
4. 1 x coaxial S/PDIF out connector
5. 2 x IEEE 1394a port
6. 8 x USB 2.0/1.1 ports
7. 1 x RJ-45 port
8. 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line Out/Microphone)

I/O Controller
1. ITE IT8720 chip

H/W Monitoring System voltage detection
1. CPU/System temperature detection
2. CPU/System fan speed detection
3. CPU overheating warning
4. CPU/System fan fail warning
5. CPU/System fan speed control (Note 4)

BIOS
1. 2 x 8 Mbit flash
2. Use of licensed AWARD BIOS
3. Support for DualBIOSâ„¢
4. PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b

Unique Features
1. Support for @BIOS
2. Support for Q-Flash
3. Support for Virtual Dual BIOS
4. Support for Download Center
5. Support for Xpress Install
6. Support for Xpress Recovery2
7. Support for EasyTune (Note 5)
8. Support for Easy Energy Saver (Note6)
9. Support for Time Repair
10. Support for Q-Share

Bundle Software
1. Norton Internet Security (OEM version)

Operating System
1. Support for Microsoft Windows Vista/ XP

Form Factor
1. ATX Form Factor; 30.5cm x 23.3 cm
