Gigabyte GA-MA790GP-UD4H AMD Chipset Driver

Gigabyte GA-MA790GP-UD4H AMD Chipset Driver 8.641 for XP descriptionCPU
1. Support for Socket AM3 / AM2+ / AM2 processors: AMD Phenom FX processor/ AMD Phenom X4 processor/ AMD Phenom X3 processor/ AMD Athlon X2 processor/ AMD Athlon processor/ AMD Sempron X2 processor/ AMD Sempron processor

Hyper Transport Bus
1. 5200/2000 MT/s

Chipset
1. North Bridge: AMD 790GX
2. South Bridge: AMD SB750

Memory
1. 4 x 1.8V DDR2 DIMM sockets supporting up to 16 GB of system memory
2. Dual channel memory architecture
3. Support for DDR2 1200 (Note 2)/1066/800 MHz memory modules

Integrated Memory
1. 128MB DDR3 SidePort memory

Audio
1. Realtek ALC889A codec
2. High Definition Audio
3. 2/4/5.1/7.1-channel
4. Support for Dolby Home Theater
5. Support for S/PDIF In/Out
6. Support for CD In

LAN
1. Realtek 8111C chip (10/100/1000 Mbit)

Expansion Slots
1. 1 x PCI Express x16 slot, running at x16 (PCIEX16_1)
2. 1 x PCI Express x16 slot, running at x8 (PCIEX8_1)
(The PCIEX16_1 and PCIEX8_1 slots support ATI Hybrid CrossFireX technology and ATI CrossFireX technology, and conform to PCI Express 2.0 standard.)
3. 3 x PCI Express x1 slots
4. 2 x PCI slots

Storage Interface
South Bridge:
1. 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
2. 6 x SATA 3Gb/s connectors supporting up to 6 SATA 3Gb/s devices
3. Support for SATA RAID 0, RAID 1, RAID5, RAID 10 and JBOD

iTE IT8718 chip:
1. 1 x floppy disk drive connector supporting up to 1 floppy disk drive

IEEE 1394
T.I. TSB43AB23 chip
1. Up to 3 IEEE 1394a ports (1 on the back panel, 2 via the IEEE 1394a bracket connected to the internal IEEE 1394a header)

USB
Integrated in the South Bridge
1. Up to 12 USB 2.0/1.1 ports (4 on the back panel, 8 via the USB brackets connected to the internal USB headers)

Internal I/O Connectors
1. 1 x 24-pin ATX main power connector
2. 1 x 8-pin ATX 12V power connector
3. 1 x floppy disk drive connector
4. 1 x IDE connector
5. 6 x SATA 3Gb/s connectors
6. 1 x CPU fan header
7. 2 x system fan header
8. 1 x power fan header
9. 1 x front panel header
10. 1 x front panel audio header
11. 1 x CD In connector
12. 1 x S/PDIF In/Out header
13. 2 x IEEE 1394a header
14. 4 x USB 2.0/1.1 headers
15. 1 x serial port header
16. 1 x chassis intrusion header
17. 1 x power LED header

Back Panel Connectors
1. 1 x PS/2 keyboard port
2. 1 x PS/2 mouse port
3. 1 x D-Sub port
4. 1 x DVI-D port
5. 1 x HDMI port
6. 1 x optical S/PDIF Out connector
7. 1 x IEEE 1394a port
8. 4 x USB 2.0/1.1 ports
9. 1 x RJ-45 port
10. 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line Out/Microphone)

I/O Controller
1. ITE IT8718 chip

H/W Monitoring
System voltage detection
1. CPU/System temperature detection
2. CPU/System fan speed detection
3. CPU overheating warning
4. CPU/System fan fail warning
5. CPU/System fan speed control

BIOS
1. 2 x 8 Mbit flash
2. Use of licensed AWARD BIOS
3. Support for DualBIOS
4. PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b

Unique Features
1. Support for @BIOS
2. Support for Q-Flash
3. Support for Virtual Dual BIOS
4. Support for Download Center
5. Support for Xpress Install
6. Support for Xpress Recovery2
7. Support for EasyTune
8. Support for Easy Energy Saver

Bundle Software
1. Norton Internet Security (OEM version)

Form Factor
1. ATX Form Factor; 30.5cm x 24.4cm


It is highly recommended to always use the most recent driver version available.

Do not forget to check with our site as often as possible in order to stay updated on the latest drivers, software and games.

Try to set a system restore point before installing a device driver. This will help if you installed a wrong driver. Problems can arise when your hardware device is too old or not supported any longer.
