Shuttle SG41J1 Barebone Intel G41 Chipset

Shuttle SG41J1 Barebone Intel G41 Chipset Driver descriptionFORM FACTOR
Shuttle Form Factor / Support mini-ITX also

PROCESSOR
Intel Core 2 Quad Core 2 Duo,Dual-Core,Celeron 400 serial support
FSB 800/1066/1333*MHz support
(*Native support)

CHIPSET
Intel G41 + ICH7

MEMORY
2 x 240 pin DDR2 DIMM slots,4GB per DIMM (Max 8GB)
Dual Channel DDR2 667/800

VGA
Built-in Intel Intel X4500
DirectX 10 Support
DVI resolution 2048 x 1526

AUDIO
Realtek ALC662
5.1 channel High Definition Audio

ETHERNET
Marvell 88E8057
IEEE 802.3u 100Base-T specification revision 1.0
100Mb/s and 1Gb/s operation
Support Wake-On-LAN function

STORAGE INTERFACE
(3) 3.0Gb/s bandwidth SATA II
(1) Ultra DMA/100 IDE channel

ONBOARD CONNECTORS
(3) SATA connectors
(1) ATA100 bus IDE connector
(2) 1x5 pin USB 2.0 header
(2) Serial Port Header
(1) ATX main power connector
(1) ATX 12V power connector
(2) set 4pin fan connectors

FRONT PANEL
(2) USB 2.0 ports
(1) Microphone-In
(1) Earphone-Out
Power-On button
Power LED
HDD LED

BACK PANEL
(1) PCI-E x16 slot
(1) PCI slot
(1) RJ45 Gigabit LAN port
(1) D-sub VGA port
(1) DVI-D VGA port
(4) USB 2.0 ports
(1) PS/2 keyboard port
(1) PS/2 mouse port
(1) Line in port
(1) Line out port
(1) MIC in port
(1) Clear CMOS button
(2) Wireless Antenna fixture

EXPANSION BAY
(2) 3.5 bay
(1) 5.25 bay

DIMENSIONS
325(L) x 215(W) x 190(H) mm

POWER
250W
Input:100-240V AC

ACCESSORIES
XPC Multilanguage Quick User Guide
XPC CD Driver (XP and Vista 32 / 64 bit and Win7 32/ 64 bit)
1* Power cord
1* IDE cable (pre-install)
1* SATA cable (pre-install)
1* 4 pin to SATA power cable
Screws
