Asus M4A88TD-V EVO/USB3 Realtek LAN Driver 5.754.308/6.235.304/7.17.304 for

Asus M4A88TD-V EVO/USB3 Realtek LAN Driver 5.754.308/6.235.304/7.17.304 for XP/Vista/Win7 descriptionCPU
AMD Socket AM3 ;PhenomII /AthlonII /Sempron 100 Series Processors
AMD 140W CPU Support
AMD Cool \'n\' Quiet Technology
Supports 45nm CPU

Chipset
AMD 880G/SB850

System Bus
Up to 5200 MT/s ; HyperTransport 3.0

Memory
4 x DIMM, Max. 16 GB, DDR3 2000(O.C.)/1333/1066 ECC,Non-ECC,Un-buffered Memory
Dual Channel memory architecture
*AMD AM3 100 and 200 series CPU support up to DDR3 1066MHz.
*Due to OS limitation, when installing total memory of 4GB capacity or more, Windows 32-bit operation system may only recognize less than 3GB. Install a 64-bit WindowsWindows OS when you want to install 4GB or more memory on the motherboard.

Expansion Slots
2 x PCIe 2.0 x16 , support ATI CrossFireX Technology (blue @ x16 mode,gray @ x4 mode)
1 x PCIe 2.0 x1
3 x PCI

VGA
Integrated ATI Radeon HD 4250 GPU
- Supports HDMI Technology with max. resolution up to 1920 x 1200 (1080P)
- Supports Dual-link DVI with max. resolution up to 2560x1600 @60Hz
- Supports D-Sub with max. resolution up to 2048x1536 @85Hz
- Dual independent displays support with HDMI / DVI and D-Sub
- Supports DirectX 10.1, OpenGL 2.0, Shader Model 4.1, Universal Video Decoder (UVD) 2.0
- Hardware Decode Acceleration for H.264,VC-1, and MPEG-2
- Maximum shared memory of 1GB
- Hybrid CrossFireX Support

Integrated Memory
- SidePort Memory - onboard 128MB DDR3 1333 memory

Storage
SB850 Chipset
5 xSATA 6.0 Gb/s ports with RAID 0, 1, 5, 10 and JBOD
1 x eSATA port (6Gb/s ready)

VT6330 controller:
- 1 x Ultra DMA 133/100/66 for up to 2 PATA devices

LAN
Realtek 8111E Gigabit LAN controller featuring AI NET2

Audio
ALC892 8-Channel High Definition Audio CODEC

IEEE 1394
VIA VT6330 controller supports 2 x 1394a port(s) (1 at mid-board; 1 at back panel)

USB
12 USB 2.0/1.1 ports (8 ports at mid-board, 4 ports at back panel)
2 x USB 3.0 ports (blue, at back panel)

ASUS Unique Features
ASUS Xtreme Design
ASUS Hybrid Processor – TurboV EVO
- Turbo Unlocker, TurboV, Auto Tuning, CPU Level UP and GPU Boost
ASUS Hybrid OS – Express Gate
ASUS Hybrid Switches
- Turbo Key II
- Core Unlocker
ASUS Exclusive Features
- MemOK!
- Anti-Surge protection
ASUS Power Solutions:
- 8+2 Phase Power Design
- EPU
ASUS Quiet Thermal Solution:
- ASUS Fanless Design: Stylish heat sink solution
- ASUS Fan Xpert
ASUS EZ DIY:
- ASUS CrashFree BIOS 3
- ASUS O.C. Profile
- ASUS MyLogo 2
- ASUS EZ Flash 2

Overclocking Features
Intelligent overclocking tools
- TurboV EVO
- GPU BOOST
- Turbo Key II
Precision Tweaker 2
- vCore: Adjustable CPU voltage at 0.003125V increment
- vChipset (N.B.): Adjustable chipeset voltage at 0.003125V increment
- vDIMM: Adjustable DRAM voltage at 0.015V increment
SFS (Stepless Frequency Selection)
- PCI Express frequency tuning from 100MHz up to 150MHz at 1MHz increment
- HT frequency tuning from 100MHz up to 550MHz at 1MHz increment
Overclocking Protection
- ASUS C.P.R.(CPU Parameter Recall)

Back Panel I/O Ports
1 x PS/2 Keyboard/Mouse Combo port
1 x DVI
1 x D-Sub
1 x HDMI
1 x S/PDIF Out (optical)
1 x IEEE 1394a
1 x LAN(RJ45) port
4 x USB 2.0/1.1
8 -Channel Audio I/O
2 x USB 3.0 ports (blue)
1 x eSATA port

Internal I/O Connectors
4 x USB connectors (8 ports)
1 x IDE connector
1 x IEEE 1394a connector
1 x CPU Fan connector
1 x Chassis Fan connector
1 x Power Fan connector
1 x Core Unlocker switch
1 x Turbo Key II switch
1 x MemOK! Button
1 x COM connector
5 x SATA 6Gb/s connectors
1 x Front panel audio connector
1 x S/PDIF Out Header
24-pin ATX Power connector
8-pin ATX 12V Power connector
System Panel

BIOS
16 Mb Flash ROM , AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.5, ACPI 2.0a, ASUS EZ Flash 2, ASUS CrashFree BIOS 3

Manageability
WOL by PME,WOR by PME,WOR by Ring,PXE

Accessories
User\'s manual
1 x UltraDMA 133/100/66 cable
4 x Serial ATA cables (2@6Gb/s, 2 @ 3Gb/s)
1 x Q-Connector (retail version only)
1 x Q-shield

Support Disc
Drivers
ASUS PC Probe II
Express Gate
Anti-virus software (OEM version)
ASUS Update
AMD OverDrive Utility (AOD)

Form Factor
ATX Form Factor
12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )

It is highly recommended to always use the most recent driver version available.

Do not forget to check with our site as often as possible in order to stay updated on the latest drivers, software and games.

Try to set a system restore point before installing a device driver. This will help if you installed a wrong driver. Problems can arise when your hardware device is too old or not supported any longer.
