Gigabyte GA-MA74GM-S2H (rev. 4.0) Realtek Ethernet Diagnostics Utility 1.0.0.4 descriptionCPU
1. Support for AM3/AM2+/AM2 processors: AMD Phenom II processor/AMD Phenom processor /AMD Athlon II processor/AMD Athlon processor/AMD Sempron processor
* If you install AMD AM3/ AM2+ CPU on AM2 motherboard, the system bus speed will downgrade from HT3.0 (5200MT/s) to HT1.0 (2000 MT/s) spec; however, the frequency of AM3/ AM2+ CPU will not be impacted.

Hyper Transport Bus
1. 2000 MT/s

Chipset
1. North Bridge: AMD 740G
2. South Bridge: AMD SB710

Memory
1. 2 x 1.8V DDR2 DIMM sockets supporting up to 8 GB of system memory
2. Dual channel memory architecture
3. Support for DDR2 1066/800/667 MHz memory modules
4. Support for non-ECC memory modules

Onboard Graphics
Integrated in the North Bridge:
1. 1 x D-sub port
2. 1 x DVI-D port
3. 1 x HDMI port

Audio
1. Realtek ALC888B codec
2. High Definition Audio
3. 2/4/5.1/7.1-channel
4. Support for S/PDIF Out
5. Support for S/PDIF In
6. Support for CD In

LAN
1. Realtek 8111D chip (10/100/1000 Mbit)

Expansion Slots
1. 1 x PCI Express x16 slot, running at x16
2. 1 x PCI Express x1 slot
3. 2 x PCI slots

Storage Interface
South Bridge:
1. 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
2. 4 x SATA 3Gb/s connectors supporting up to 4 SATA 3Gb/s devices
3. Support for SATA RAID 0, RAID 1, RAID 10 and JBOD

iTE IT8718 chip:
1. 1 x floppy disk drive connector supporting up to 1 floppy disk drive

USB
Integrated in the South Bridge
1. Up to 10 USB 2.0/1.1 ports (8 on the back panel, 4 via the USB brackets connected to the internal USB headers)

Internal I/O Connectors
1. 1 x 24-pin ATX main power connector
2. 1 x 4-pin ATX 12V power connector
3. 1 x floppy disk drive connector
4. 1 x IDE connector
5. 4 x SATA 3Gb/s connectors
6. 1 x CPU fan header
7. 1 x system fan header
8. 1 x front panel header
9. 1 x front panel audio header
10. 1 x CD In connector
11. 1 x SPDIF In/Out header
12. 2 x USB 2.0/1.1 headers
13. 1 x Serial port header
14. 1 x clearing CMOS jumper

Back Panel Connectors
1. 1 x PS/2 keyboard or PS/2 mouse port
2. 1 x D-Sub port
3. 1 x DVI-D port
4. 1 x HDMI port
5. 8 x USB 2.0/1.1 ports
6. 1 x RJ-45 port
7. 3 x audio jacks (Line In/Line Out/Microphone)

I/O Controller
1. ITE IT8718 chip

H/W Monitoring
System voltage detection
1. CPU/System temperature detection
2. CPU/System fan speed detection
3. CPU overheating warning
4. CPU/System fan fail warning
5. CPU/System fan speed control

BIOS
1. 2 x 8 Mbit flash
2. Use of licensed AWARD BIOS
3. Support DualBIOS
4. PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b

Unique Features
1. Support for @BIOS
2. Support for Download Center
3. Support for Xpress BIOS Rescue
4. Support for Q-Flash
5. Support for EasyTune
6. Support for Xpress Install
7. Support for Xpress Recovery2

Bundle Software
1. Norton Internet Security (OEM version)

Form Factor
1. Micro ATX Form Factor; 24.3cm x 22.0cm
