Gigabyte GA-MA78LM-S2H (rev. 1.3) Realtek Ethernet Diagnostics Utility

Gigabyte GA-MA78LM-S2H (rev. 1.3) Realtek Ethernet Diagnostics Utility 1.0.0 descriptionCPU
1. Support for Socket AM3 / AM2+ / AM2 processors: AMD Phenom II processor/ AMD Phenom processor/ AMD Athlon II processor/ AMD Athlon processor/ AMD Sempron processor

Hyper Transport Bus
1. 5200/2000 MT/s

Chipset
1. North Bridge: AMD 760G
2. South Bridge: AMD SB710

Memory
1. 2 x 1.8V DDR2 DIMM sockets supporting up to 8 GB of system memory
2. Dual channel memory architecture
3. Support for DDR2 1200(O.C.) /1066/800 MHz memory modules
4. Support for non-ECC memory modules

Onboard Graphics
Integrated in the North Bridge:
1. 1 x D-Sub port
2. 1 x DVI-D port
3. 1 x HDMI port

Audio
1. Realtek ALC888B codec
2. High Definition Audio
3. 2/4/5.1/7.1-channel
4. Support for S/PDIF In
5. Support for S/PDIF Out
6. Support for CD In

LAN
1. Realtek 8111D chip (10/100/1000 Mbit)

Expansion Slots
1. 1 x PCI Express x16 slot, running at x16
(The PCI Express x16 slot conforms to PCI Express 2.0 standard.)
2. 1 x PCI Express x1 slots
3. 2 x PCI slots

Storage Interface
South Bridge:
1. 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
2. 4 x SATA 3Gb/s connectors supporting up to 4 SATA 3Gb/s devices
3. Support for SATA RAID 0, RAID 1, RAID 10 and JBOD

iTE IT8718 chip:
1. 1 x floppy disk drive connector supporting up to 1 floppy disk drive

USB
Integrated in the South Bridge
1. Up to 12 USB 2.0/1.1 ports (8 on the back panel, 4 via the USB brackets connected to the internal USB headers)

Internal I/O Connectors
1. 1 x 24-pin ATX main power connector
2. 1 x 4-pin ATX 12V power connector
3. 1 x floppy disk drive connector
4. 1 x IDE connector
5. 4 x SATA 3Gb/s connectors
6. 1 x CPU fan header
7. 1 x system fan header
8. 1 x front panel header
9. 1 x front panel audio header
10. 1 x CD In connector
11. 1 x S/PDIF In/Out header
12. 2 x USB 2.0/1.1 headers
13. 1 x serial port header
14. 1 x clearing CMOS jumper

Back Panel Connectors
1. 1 x PS/2 keyboard or PS/2 mouse port
2. 1 x D-Sub port
3. 1 x DVI-D port
4. 1 x HDMI port
5. 8 x USB 2.0/1.1 ports
6. 1 x RJ-45 port
7. 3 x audio jacks (Line In/Line Out/Microphone)

I/O Controller
1. ITE IT8718 chip

H/W Monitoring
System voltage detection
1. CPU/System temperature detection
2. CPU/System fan speed detection
3. CPU overheating warning
4. CPU/System fan fail warning
5. CPU/System fan speed control

BIOS
1. 2 x 8 Mbit flash
2. Use of licensed AWARD BIOS
3. Support for DualBIOS
4. PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b

Unique Features
1. Support for @BIOS
2. Support for Q-Flash
3. Support for Download Center
4. Support for Xpress Install
5. Support for Xpress Recovery2
6. Support for EasyTune

Bundle Software
1. Norton Internet Security (OEM version)

Form Factor
1. Mirco ATX Form Factor; 24.3cm x 22.0 cm
