Gigabyte GA-M78SM-S2H Nvidia VGA Driver 15.49 for Vista descriptionCPU
1. Support for Socket AM3 / AM2+ / AM2 processors: AMD Phenom FX processor/ AMD Phenom X4 processor/ AMD Phenom X3 processor/ AMD Athlon X2 processor/ AMD Athlon processor/ AMD SempronX2 processor / AMD Sempron processor

Hyper Transport Bus
1. 5200/2000 MT/s

Chipset
1. North Bridge: NVIDIA GeForce 8200 chipset

Memory
1. 2 x 1.8V DDR2 DIMM sockets supporting up to 8 GB of system memory
2. Dual channel memory architecture
3. Support for DDR2 1066 (Note 2)/800/667 MHz memory modules

Audio
1. Realtek ALC888 codec
2. High Definition Audio
3. 2/4/5.1/7.1-channel
4. Support for S/PDIF Out
5. Support for CD In

LAN
1. Realtek 8211B chip (10/100/1000 Mbit)

Expansion Slots
1. 1 x PCI Express x16 slot, supporting Hybrid SLI technology
(The PCI Express x16 slot conforms to PCI Express 2.0 standard.)
2. 1 x PCI Express x1 slot
3. 2 x PCI slots

Storage Interface
NVIDIA GeForce 8200 chipset:
1. 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
2. 6 x SATA 3Gb/s connectors supporting up to 6 SATA 3Gb/s devices
3. Support for SATA RAID 0, RAID 1, RAID 5, RAID 0+1 and JBOD

iTE IT8718 chip:
1. 1 x floppy disk drive connector supporting up to 1 floppy disk drive

USB
Integrated in the NVIDIA GeForce 8200 chipset
1. Up to 12 USB 2.0/1.1 ports (4 on the back panel, 8 via the USB brackets connected to the internal USB headers)

Internal I/O Connectors
1. 1 x 24-pin ATX main power connector
2. 1 x 4-pin ATX 12V power connector
3. 1 x floppy disk drive connector
4. 1 x IDE connector
5. 6 x SATA 3Gb/s connectors (SATA2_4 & SATA2_5 only can run under AHCI or RAID mode due to NVIDIA chipset limitation)
6. 1 x CPU fan header
7. 1 x system fan header
8. 1 x front panel header
9. 1 x front panel audio header
10. 1 x CD In connector
11. 1 x S/PDIF Out header
12. 4 x USB 2.0/1.1 headers
13. 1 x serial port header
14. 1 x power LED header
15. 1 x chassis intrusion header

Back Panel Connectors
1. 1 x PS/2 keyboard port
2. 1 x Parallel port
3. 1 x D-Sub port
4. 1 x DVI-D port
5. 1 x HDMI port
6. 1 x optical S/PDIF Out connector
7. 4 x USB 2.0/1.1 ports
8. 1 x RJ-45 port
9. 3 x audio jacks (Line In/Line Out/Microphone)

I/O Controller
1. ITE IT8718 chip

H/W Monitoring
1. System voltage detection
2. CPU/System temperature detection
3. CPU/System fan speed detection
4. CPU overheating warning
5. CPU/System fan fail warning
6. CPU/System fan speed control

BIOS
1. 1 x 4 Mbit flash
2. Use of licensed AWARD BIOS
3. PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b

Unique Features
1. Support for @BIOS
2. Support for Download Center
3. Support for Q-Flash
4. Support for EasyTune
5. Support for Xpress Install
6. Support for Xpress Recovery2
7. Support for Virtual Dual BIOS

Bundle Software
1. Norton Internet Security (OEM version)

Form Factor
1. Micro ATX Form Factor; 24.4cm x 21cm
