Shuttle SX58J3 Barebone IMSM

Shuttle SX58J3 Barebone IMSM Driver descriptionFORM FACTOR: Shuttle Form Factor
PROCESSOR: Intel Core i7 family
CHIPSET: Intel X58 + ICH10R
MEMORY: 4 x 240pin DDR3 DIMM slots,4GB per DIMM(Max 16GB)
Support Triple channel DDR3 1066/1333/1600(OC)MHz
*DIMMs with voltage setup over 1.65V may damage your CPU
AUDIO: Realtek ALC888
7.1 channel High Definition Audio
ETHERNET: (2) Marvell 8057
10Mb/s,100Mb/s,1Gb/s operation
Support Wake-ON-LAN function
STORAGE INTERFACE:
(4) on board 3.0Gb/s bandwidth SATA (RAID 0,1,10,5)
(1) 3.0Gb/s bandwidth eSATA in back panel
ONBOARD CONNECTORS:
(1) 4 Pin fan connector
(1) 3 Pin fan connector
(4) SATA 2.0 connectors
(1) ATX main power (2*10)
(1) ATX main power (2*4)
(2) 2x5 pin USB header
(1) AUX-in header
(1) Power button header
(1) front audio connector
(1) SPIDIF Optical out
(1) LPC port
(2) PCIE x 16 support ATI Crossfire and Nvidia SLI technology
FRONT PANEL:
(1) USB 2.0 Port
(1) USB 2.0+E-SATA Port
(1) External microphone jack 1/8”
(1) External headphone jack 1/8”
(1) 4 in 1 card reader
Power button
HDD/ODD Led
BACK PANEL:
(8) USB 2.0 Ports
(2) RJ45
(1) Audio Front out jack 1/8”
(1) Audio Rear surround jack 1/8”
(1) Audio Side surround jack 1/8”
(1) Audio Center/Bass jack 1/8”
(1) Line in jack 1/8”
(1) eSATA
(1) eSATA external power connector
(1) CMOS clear button
DIMENSIONS:
333(L) x 215(W) x 204(H) mm (w/foot rubber)
POWER: 500W
Input:100 - 240V AC
Support 80 PLUS Bronze
DIMENSIONS:(W) x (H) x(D) mm
ACCESSORIES:
XPC Multi-Language User Guide
XPC DVD Driver (include Adobe Reader 8.1)
I.C.E Technology CPU heat-pipe
Cables:
(2) SATA cable (pre-install)
(1) 1 set 4pin to SATA power cable
(1) Power cord
Others: Screws,Heatsink Compound
