Gateway EC14 Notebooks Intel Chipset Driver 9.1.1.1015 descriptionProcessor
Intel Pentium processor SU4100 (2 MB L2 cache, 1.30 GHz, 800 MHz FSB, 10 W), supporting Intel 64 architecture
Intel Celeron processor SU2300 (1 MB L2 cache, 1.20 GHz, 800 MHz FSB, 10 W), supporting Intel 64 architecture
Intel Celeron processor 743 (1 MB L2 cache, 1.30 GHz, 800 MHz FSB, 10 W), supporting Intel 64 architecture
Intel Celeron processor 743 (1 MB L2 cache, 1.20 GHz, 800 MHz FSB, 10 W), supporting Intel 64 architecture

Chipset
Mobile Intel GS45 Express Chipset

Memory
Dual-channel DDR2 SDRAM support
Up to 2 GB of DDR2 667 MHz memory, upgradeable to 4 GB using two soDIMM modules

Video
Mobile Intel GS45 Express Chipset with integrated 3D graphics, featuring Intel Graphics Media Accelerator 4500MHD (Intel GMA 4500MHD) with up to 1759 MB of Intel Dynamic Video Memory Technology 5.0 (64 MB of dedicated video memory, up to 1695 MB of shared system memory), supporting Microsoft DirectX 10
Dual independent display support
16.7 million colors
MPEG-2/DVD decoding
WMV9 (VC-1) and H.264 (AVC) decoding
HDMI (High-Definition Multimedia Interface) with HDCP (High-bandwidth Digital Content Protection) support

LCD Properties
11.6" HD 1366 x 768 pixel resolution, high-brightness (200-nit) Gateway Ultrabright LED-backlit TFT LCD, supporting simultaneous multi-window viewing
16:9 aspect ratio

Hard Drive
2.5" 9.5 mm 160/250/320 GB or higher hard disk drive

Media Card Reader
Media card reader supporting:
Secure Digital (SD) Card
MultiMediaCard (MMC)
Reduced-Size Multimedia Card (RS-MMC)
Memory Stick (MS)
Memory Stick PRO (MS PRO)
xD-Picture Card (xD)

Optical Drive
No optical drive

Audio
Optimized 2nd Generation Dolby Sound Room audio enhancement, featuring:
Dolby Headphone
Dolby Natural Bass
Dolby Sound Space Expander
Two built-in stereo speakers
High-definition audio support
S/PDIF (Sony/Philips Digital Interface) support for digital speakers
Built-in microphone
MS-Sound compatible

Peripheral Subsystem
Integrated high-def webcam
5-in-1 card reader supporting MMC, SD, xD, MS, and MS PRO cards
Built-in microphone
Three USB 2.0 ports
HDMI port with HDCP support
External display (VGA) port
Headphone/speaker/line-out jack with S/PDIF support
Microphone-in jack
Ethernet (RJ-45) port
DC-in jack for AC adapter

Communication
WLAN: Integrated Gateway 802.11b/g/Draft-N Wi-Fi CERTIFIED network connection
WLAN: Intel WiFi Link 1000 802.11b/g/Draft-N Wi-Fi CERTIFIED network connection, supporting MIMO technology (for Intel Celeron 743 and SU4100 only)
WPAN: Bluetooth 2.1+EDR (Enhanced Data Rate)
LAN: Gigabit Ethernet, Wake-on-LAN ready
WWAN: UMTS/HSPA at 850/900/1900/2100 MHz and quad-band GSM/GPRS/EDGE(850/900/1800/1900 MHz), upgradeable to 7.2 Mb/s HSDPA and 5.7 Mb/s HSUPA, supporting receiver diversity and equalizing at 2100 MHz (for 3G models). Optional support for receiver diversity and equalizing on 2100 MHz

Keys and Controls
84-/85-/88-key keyboard
Multi-gesture touchpad pointing device, supporting:
Circular-motion scrolling
Pinch-action zoom
Page flip
10 function keys, four cursor keys, Windows key, international language support
Power button with LED
Easy-access switches with LED: Bluetooth, WLAN/WWAN

Power
ACPI 3.0 CPU power management standard: supports Standby and Hibernation power-saving modes
23.76 W 2200 mAh 3-cell
47.52 W 4400 mAh 6-cell Li-ion battery pack:
6-hour battery life (for Intel Celeron 723 only)
62.16 W 5600 mAh 6-cell Li-ion battery pack:
7-hour battery life (for Intel Celeron 723 only)
30 W AC adapter

Dimensions
(W × D × H)     11.22 × 8.03 × 0.87/1.18 inches (285 × 204 × 22.1/30.0 mm)
3.08 lbs. (1.40 kg) with 6-cell battery

Software
Gateway Games
Gateway PowerSave Solution
Gateway Identity Card
Gateway Recovery Management
Gateway Updater
Adobe Flash Player 10
Adobe Reader
Cyberlink PowerDVD
Google Toolbar
Google Setup
Microsoft Silverlight
Microsoft Windows Live Essentials Wave 3
Microsoft Works with Office Home and Student 2007 Trial
Norton Online Backup
Norton Internet Security 2009 (60 days)
Symantec Virus Definitions

Other Color Options:
NightSky Black
Cherry Red
